| Weight | 51 oz |
|---|---|
| Dimensions | 10 × 5 × 8.5 in |
| Radiator | 3″ diameter concentric rings with integral 4-wire RTD sensor |
| Meter | 4-wire RTD thermometer |
| Ambient Operating Range | -40° to 158°F (-40° to 70°C) |
| System Accuracy | ±0.3°F or ±0.2°C over entire range |
| Temperature Scale | °F or °C user selectable |
| Display | 4-digit 1″ high LCD |
| Display Resolution | 0.1° |
| Display Update Rate | 10 seconds |
| Repeatability | 0.1 °F or °C |
| Heating Method | None, assumes the ambient temperature |
| Emissivity | 0.95 or ± 0.02 |
| Power | 1 – 3.6 Volt Lithium Thionyl Chloride Battery, size AA |
| Battery Life | Approximately 3 years, with “Low Bat” indicator. Turning off unit when not in use will extend battery life. |
| Case | Pelican® brand case, model 1150 |
| Case Rating | IP67 (1 meter submersion for 30 minutes with case closed) |
| Dimensions | 9.12 inches x 7.56 inches x 4.32 inches (23.2 cm x 19.2 cm x 11.1 cm) |
| Weight | 2.85 lbs. (1.29 kg) |
| Included | User Manual |
| CE Approval | No |
| HTS Code | 9027.50.1000 |
| Warranty | Two Year Warranty covers defects in materials and workmanship |
This portable ambient temperature black body is designed for precise single-point calibration verification of thermal imaging cameras and infrared thermometers. The Wahl HSICBB-P Calibration Black Body offers an accuracy of ±0.3°F (0.2°C), making it a reliable, cost-effective solution for verifying instrument accuracy in both in-house and field applications. Easy to operate, this black body allows users to select between °F and °C settings. Simply set your camera or thermometer to the correct emissivity, aim at the black body’s target area, and compare readings to ensure your device is within tolerance limits and to correct for zero error.
1. What is the weight of the calibration device?
The calibration device weighs 51 oz and is housed in a durable Pelican® model 1150 case.
2. What are the dimensions of the calibration unit?
The unit itself measures 10 × 5 × 8.5 inches, while the Pelican® case is 9.12 × 7.56 × 4.32 inches (23.2 × 19.2 × 11.1 cm).
3. What type of radiator and sensor does this device use?
It features a 3-inch diameter radiator with concentric rings, and an integral 4-wire RTD sensor for accurate temperature readings.
4. What thermometer is used in the calibration system?
The system uses a 4-wire RTD thermometer, known for high accuracy in calibration checks.
5. What is the ambient operating range?
This unit operates effectively within an ambient range of -40°F to 158°F (-40°C to 70°C).
6. What is the system accuracy?
The system has an accuracy of ±0.3°F or ±0.2°C across its entire operating range.
7. Can I select between Fahrenheit and Celsius?
Yes, the temperature scale is user-selectable between °F and °C.
8. What is the display resolution and update rate?
The LCD display has a 0.1° resolution and updates every 10 seconds.
9. Does the device have a heating element?
No, this device does not have a heating element and relies on ambient temperature.
10. What is the emissivity of the unit?
The emissivity is 0.95 with a tolerance of ±0.02.
11. What power source does the unit require?
The device runs on a 1–3.6 Volt Lithium Thionyl Chloride AA battery, with an estimated battery life of 3 years.
12. Is the case waterproof?
Yes, the case is IP67 rated, meaning it can be submerged in 1 meter of water for up to 30 minutes.
13. Is there a warranty?
The device comes with a two-year warranty covering defects in materials and workmanship.
14. Does the device have CE approval?
No, this unit does not have CE approval.
15. What is the HTS code for this calibration device?
The Harmonized Tariff Schedule (HTS) code is 9027.50.1000.
